What Tungsten for Stainless Steel? A Comprehensive Guide
Choosing the right tungsten for welding or machining stainless steel depends heavily on the specific application and desired outcome. This isn't a simple "one size fits all" scenario. Different grades of tungsten electrodes offer varying properties crucial for achieving strong, clean, and aesthetically pleasing welds. This guide will delve into the factors influencing tungsten selection for stainless steel applications and answer some common questions.
What are the Different Types of Tungsten Electrodes?
Tungsten electrodes are categorized by their purity and the addition of other elements. These additions dramatically impact their arc characteristics and suitability for different metals. Common types used with stainless steel include:
-
Pure Tungsten (WP): Excellent for applications requiring high purity and minimal contamination, such as welding thin materials or those demanding a very clean weld. However, it's less resistant to wear and tear compared to other types.
-
2% Thoriated Tungsten (WT20): Offers increased arc starting and stability compared to pure tungsten. It's a popular choice for many applications, including stainless steel. However, it's important to note that thorium is radioactive, posing a health hazard if mishandled. Proper safety precautions are paramount when using thoriated tungsten.
-
2% Ceriated Tungsten (WC20): A less radioactive alternative to thoriated tungsten. It provides similar arc starting and stability properties with better high-frequency characteristics, making it suitable for TIG welding stainless steel.
-
Lanthanated Tungsten (WL): Offers excellent arc starting and stability, along with enhanced durability. It produces a sharper arc, making it useful for precision welding of stainless steel. Different lanthanum percentages (e.g., WL15, WL20) offer varying characteristics.
-
Zirconiated Tungsten (WZ): Provides good arc stability and is resistant to contamination. While usable for stainless steel, it’s less commonly chosen than ceriated or lanthanated options.
Which Tungsten is Best for Stainless Steel TIG Welding?
The optimal tungsten choice depends on factors such as:
-
Thickness of the stainless steel: For thin stainless steel, pure tungsten or a low-ceriated tungsten may be preferred to minimize heat input and prevent burn-through. Thicker stainless steel allows the use of more robust options like ceriated or lanthanated tungsten.
-
Type of stainless steel: The specific grade of stainless steel might influence tungsten selection. Some grades may be more sensitive to contamination than others.
-
Welding position: For out-of-position welding (overhead, vertical), a tungsten with excellent arc stability like ceriated or lanthanated tungsten is advantageous.
Generally, ceriated (WC20) or lanthanated (WL) tungsten electrodes are popular and effective choices for TIG welding most stainless steels. They strike easily, offer good arc stability, and are relatively durable. If minimizing radiation risk is paramount, ceriated tungsten is the preferred option over thoriated.
What Size Tungsten Electrode Should I Use for Stainless Steel?
The diameter of your tungsten electrode should be selected based on the amperage used. Higher amperage requires a larger diameter tungsten to prevent overheating and premature failure. Consult your welding machine's manual for the recommended electrode size based on your amperage range.
How Do I Sharpen Tungsten Electrodes for Stainless Steel Welding?
Proper tungsten sharpening is vital for achieving a clean, consistent weld. A properly sharpened tungsten creates a focused arc that minimizes spatter and ensures better penetration. Use a grinding wheel or a tungsten grinding tool specifically designed for this purpose. The goal is to create a precise point or a slight blunt end, depending on preference and amperage. Avoid excessive grinding that could damage the electrode.
What Happens if I Use the Wrong Tungsten for Stainless Steel?
Using an inappropriate tungsten can lead to several problems:
- Poor arc stability: The arc may flicker or be difficult to maintain.
- Excessive spatter: Increased spatter will lead to an uneven and messy weld.
- Weld contamination: The wrong tungsten could contaminate the weld pool, affecting the properties of the weld.
- Tungsten inclusion: Pieces of the electrode may break off and become embedded in the weld, weakening it.
Choosing the correct tungsten electrode is a crucial aspect of successful stainless steel welding. By understanding the properties of different tungsten types and carefully considering the specific application, welders can ensure high-quality, reliable welds. Remember to always prioritize safety, especially when dealing with thoriated tungsten.
